Electric Forklift 4-5 Tonne

Electric Forklift 4-5 Tonne

K Series

The lithium battery powered forklifts can lift materials up to 4 to 5 tons. Adopting the integrated design of the drive axle and the gearbox, the forklift is energy-saving due to high transmission efficiency and short braking time.

  • Capacity4000-5000 kg
  • Lift Height3000 mm
  • Travel Speed13-14 km/h
  • Min. Turning Radius2570-2800 mm
Request a Quote
Features
  • The hydraulic steering axle provides larger steering angle and reduces the turning radius, which helps save maintenance time and costs.
  • With an integrated design, the forklift is made without any bolts, which increases the total strength by 20%. This design increases operational safety and empowers the forklift to carry out complex material handling tasks in uneven and winding terrains.
Applications

Material handling in warehouses, logistics centers and distribution centers.

Technical Specifications
Model CPD40 CPD50S
Characteristics Power Lithium battery
Capacity kg 4000 5000
Load Centre mm 500 500
Lift Height mm 3000 3000
Min. Turning Radius mm 2570 2800
Performance Travel Speed Load/no load km/h 13/14 13/14
Lift Speed Load/no load mm/s 290/420 220/230
Dimensions Total Length Without fork mm 2900 3139
Total Width mm 1245 1480
Max. Lifting Height mm 4265 4200
Mast Height mm 2100 2270
Chassis Tyre Front 250-20 300-15
Rear 6.50-10 700-12
Wheelbase mm 1700 2000
Service Weight No load kg 4950 6800
Power Battery Electric tension V 76.8 80
Capacity Ah 280 460
Motor Drive motor kW 12 16
Oil pump motor kW 21 23
Is it safe to use lithium batteries?
It’s safe to use lithium batteries in electric forklifts since they are sealed to prevent electrolyte leakage and toxic fume release. With less emissions, the electric forklifts secure operators’ health and minimize the risk of fire during operation.
What are the advantages of using lithium batteries?
  • Lithium batteries have longer service life, which helps reduce maintenance costs.
  • Using lithium batteries, the forklift enjoys the benefits of less energy loss and increased operational time.
  • Lithium batteries feature flexible charging which enables the forklift to be online for 24 hours and operate before reaching full charge.
  • Lithium batteries have less emissions and are environmental-friendly.
